NEC DTE-29U1TH - All Electrical Parts List

Service Manual CP-785F
-51-
LOC PART NAME PART Code PART Description Remark
6-2. All Electrical Parts List
-Main PCB Assembly Parts List
C101 C ELECTRO CEXF1H100V 50V RSS 10MF (5X11) TP
C102 C ELECTRO CEXF1H470V 50V RSS 47MF (6.3X11) TP
C103 C CERA CCXB1H102K 50V B 1000PF K (TAPPING)
C104 C CERA CCXB1H102K 50V B 1000PF K (TAPPING)
C106 C ELECTRO CEXF1H220V 50V RSS 22MF (5X11) TP
C108 C CERA CCXB1H101K 50V B 100PF K (TAPPING)
C120 C CERA CCXB1H102K 50V B 1000PF K (TAPPING)
C121 C ELECTRO CEXF1H100V 50V RSS 10MF (5X11) TP
C305 C ELECTRO CEXF1E471V 25V RSS 470MF (10X16) TP
C313 C MYLAR CMXM2A104J 100V 0.1MF J (TP)
C315 C ELECTRO CEXF2C470C 160V RUS 47MF (13X25) TP
C320 C CERA SEMI CBXF1H104Z 50V F 0.1MF Z (TAPPING)
C350 C CERA CCXF1H473Z 50V F 0.047MF Z (TAPPING)
C351 C CERA CCXF1H473Z 50V F 0.047MF Z (TAPPING)
C370 C MYLAR CMXM2A473J 100V 0.047MF J (TP)
C401 C ELECTRO CEXF1H100C 50V RUS 10MF (5X11) TP
C402 C MYLAR CMYH3C692J 1.6KV BUP 6900PF J
C404 C MYLAR CMYH3C692J 1.6KV BUP 6900PF J
C408 C MYLAR CMYE2G394J 400V PU 0.39MF J
C409 C CERA CXCH2H470J 500V CH 47PF J (TAPPING)
C412 C ELECTRO CEXF2C339C 160V RUS 3.3MF (8X11.5) TP
C414 C MYLAR CMXM2A104J 100V 0.1MF J (TP)
C418 C CERA CCXB1H102K 50V B 1000PF K (TAPPING)
C420 C CERA CCXB2H222K 500V B 2200PF K (TAPPING)
C430 C MYLAR CMXH3C122J 1.6KV BUP 1200PF J (TP)
C431 C MYLAR CMXE2D103J 200V PU 0.01MF J (TP)
C440 C MYLAR CMXE2G273J 400V PU 0.027MF J (TP)
C499 C ELECTRO CEYD1H689W 50V RHD 6.8MF (16X35.5)
C501 C ELECTRO CEXF1H479V 50V RSS 4.7MF (5X11) TP
C502 C ELECTRO CEXF1H479V 50V RSS 4.7MF (5X11) TP
C503 C ELECTRO CEXF1H479V 50V RSS 4.7MF (5X11) TP
C509 C ELECTRO CEXF1E470V 25V RSS 47MF (5X11) TP
C511 C MYLAR CMXL1J224J 63V MEU 0.22MF J (TP)
C512 C MYLAR CMXL1J224J 63V MEU 0.22MF J (TP)
C513 C CERA SEMI CBXF1H104Z 50V F 0.1MF Z (TAPPING)
C514 C ELECTRO CEXF1E101V 25V RSS 100MF (6.3X11) TP
C515 C CERA CBZR1C222M 16V Y5R 2200PF M (AXIAL)
C516 C CERA CBZR1C472M 16V Y5R 4700PF M (AXIAL)
C517 C ELECTRO CEXF1H109V 50V RSS 1MF (5X11) TP
C518 C CERA SEMI CBXF1H104Z 50V F 0.1MF Z (TAPPING)
C519 C ELECTRO CEXF1H109V 50V RSS 1MF (5X11) TP
C520 C CERA CCZB1H102K 50V B 1000PF K (AXIAL)
C521 C CERA CCZB1H102K 50V B 1000PF K (AXIAL)
