LOC PART NAME PART Code PART Description Remark
R726 R CARBON FILM RD-AZ181J- 1/6 180 OHM J
R801 POSISTOR DPC7R0M290 2322 662 96709 COMPATIBLE( )
DDC7R0M290 ECPCD7R0M290
R802 R M-OXIDE FILM RS02Z753JS 2W 75K OHM J SMALL
R804 R FUSIBLE RF02Z158K- 2W 0.15 OHM K (TAPPING)
R805 R CARBON FILM RD-2Z100J- 1/2 10 OHM J
R806 R CARBON FILM RD-4Z472J- 1/4 4.7K OHM J
R807 R CARBON FILM RD-2Z272J- 1/2 2.7K OHM J
R808 R CARBON FILM RD-4Z911J- 1/4 910 OHM J
R810 R CARBON FILM RD-4Z102J- 1/4 1K OHM J
R811 R CARBON COMP RC-2Z565KP 1/2 5.6M OHM K
R817 R CARBON FILM RD-AZ473J- 1/6 47K OHM J
R819 R CEMENT RX10B339JQ 10W 3.3 OHM J BEN 25MM 4P
R820 R CARBON FILM RD-AZ102J- 1/6 1K OHM J
R821 R CARBON FILM RD-4Z102J- 1/4 1K OHM J
R823 R CARBON FILM RD-4Z331J- 1/4 330 OHM J When I806 is DP142(or SE140)
RD-4Z512J- 1/4 5.1K OHM J When I806 IS SE130
R829 R CARBON FILM RD-AZ223J- 1/6 22K OHM J
R830 R CARBON FILM RD-AZ332J- 1/6 3.3K OHM J
R840 R CARBON FILM RD-4Z220J- 1/4 22 OHM J
R841 R CARBON FILM RD-2Z479J- 1/2 4.7 OHM J
R842 R CARBON FILM RD-2Z479J- 1/2 4.7 OHM J
R843 R CARBON FILM RD-AZ561J- 1/6 560 OHM J
R844 WIRE COPPER 85801065GY AWG22 1/0.65 TIN COATING
R850 R CARBON FILM RD-2Z479J- 1/2 4.7 OHM J
R855 R CARBON FILM RD-4Z185J- 1/4 1.8M OHM J
R870 R CARBON FILM RD-2Z222J- 1/2 2.2K OHM J
R888 R CARBON FILM RD-AZ103J- 1/6 10K OHM J
R910 R CARBON FILM RD-AZ101J- 1/6 100 OHM J
R911 R CARBON FILM RD-AZ101J- 1/6 100 OHM J
R912 R CARBON FILM RD-AZ101J- 1/6 100 OHM J
R913 R CARBON COMP RC-2Z102K- 1/2 1K OHM K
R914 R CARBON COMP RC-2Z102K- 1/2 1K OHM K
R915 R CARBON COMP RC-2Z102K- 1/2 1K OHM K
R920 WIRE COPPER 85801065GY AWG22 1/0.65 TIN COATING
R921 R CARBON FILM RD-AZ102J- 1/6 1K OHM J
R922 R CARBON FILM RD-AZ102J- 1/6 1K OHM J
R923 R CARBON FILM RD-AZ102J- 1/6 1K OHM J
R924 R CARBON FILM RD-4Z105J- 1/4 1M OHM J
R925 R CARBON FILM RD-4Z102J- 1/4 1K OHM J
RA01 WIRE COPPER 85801065GY AWG22 1/0.65 TIN COATING
RA02 R CARBON FILM RD-AZ102J- 1/6 1K OHM J
RA03 R CARBON FILM RD-AZ102J- 1/6 1K OHM J
RA04 R CARBON FILM RD-AZ910J- 1/6 91 OHM J
RA05 R CARBON FILM RD-AZ750J- 1/6 75 OHM J
RA06 R CARBON FILM RD-AZ102J- 1/6 1K OHM J
