Service Manual CP-785F
-56-
LOC PART NAME PART Code PART Description Remark
E040 EYE LET 4856310600 BSR T0.2 (R2.3)
E043 EYE LET 4856310300 BSR T0.2 (R1.6)
E044 EYE LET 4856310300 BSR T0.2 (R1.6)
E045 EYE LET 4856310300 BSR T0.2 (R1.6)
E046 EYE LET 4856310300 BSR T0.2 (R1.6)
E047 EYE LET 4856310300 BSR T0.2 (R1.6)
E048 EYE LET 4856310300 BSR T0.2 (R1.6)
E049 EYE LET 4856310300 BSR T0.2 (R1.6)
E050 EYE LET 4856310300 BSR T0.2 (R1.6)
E051 EYE LET 4856310300 BSR T0.2 (R1.6)
E052 EYE LET 4856310300 BSR T0.2 (R1.6)
E053 EYE LET 4856310300 BSR T0.2 (R1.6)
E054 EYE LET 4856310300 BSR T0.2 (R1.6)
E057 EYE LET 4856310600 BSR T0.2 (R2.3)
E058 EYE LET 4856310600 BSR T0.2 (R2.3)
E059 EYE LET 4856310600 BSR T0.2 (R2.3)
E060 EYE LET 4856310600 BSR T0.2 (R2.3)
E061 EYE LET 4856310300 BSR T0.2 (R1.6)
E062 EYE LET 4856310300 BSR T0.2 (R1.6)
E063 EYE LET 4856310300 BSR T0.2 (R1.6)
E064 EYE LET 4856310300 BSR T0.2 (R1.6)
E066 EYE LET 4856310300 BSR T0.2 (R1.6)
E069 EYE LET 4856310300 BSR T0.2 (R1.6)
E077 EYE LET 4856310300 BSR T0.2 (R1.6)
E078 EYE LET 4856310300 BSR T0.2 (R1.6)
E079 EYE LET 4856310300 BSR T0.2 (R1.6)
E116 EYE LET 4856310600 BSR T0.2 (R2.3)
E118 EYE LET 4856310600 BSR T0.2 (R2.3)
F801 FUSE 5FWPS4022L WIDE TL 250V 4A CASE
FUSE GLASS TUBE 5FSGB4022L SEMKO TL 4A 250V MF51 COMPATIBLE( )
F801A CLIP FUSE 4857415001 PFC5000-0702 WHEN 5FSGB4022L IS USED
F801B CLIP FUSE 4857415001 PFC5000-0702 WHEN 5FSGB4022L IS USED
G900 SPARK GAP 4SG0DX0001 SSG-102-A1(1.0KV) TAP
G901 SPARK GAP 4SG0DX0001 SSG-102-A1(1.0KV) TAP
G902 SPARK GAP 4SG0DX0001 SSG-102-A1(1.0KV) TAP
G903 SPARK GAP 4SG0DX0001 SSG-102-A1(1.0KV) TAP
I301 HEAT SINK ASS‘Y PTA2SW8214 1TDA8358J- + 7174301011
I601
IC SOUND PROCESSOR
1MSP3410V3 MSP3410G-PP-B8-V3
I602 HEAT SINK ASS‘Y PTA2SW8215 1TDA8946J- + 7174301011
I702 IC 1AT24C08PC AT24C08-10PC
I703 IC PREAMP 1TS0P1238W TS0P1238WI1
I801 HEAT SINK ASS‘Y PTF2SW7920 1STRF6653- + 7174301211
I804 IC PHOTO COUPLER 1KP1010C KP-1010C
I806 IC ERROR AMP 1DP142 DP142
SE130N ==>R823 Must be 330ohm
I810 THYRISTOR TX0202DA X0202DA1BA2
I820 IC REGULATOR 1KA7805 - KA7805
