CONFIGRATION GUIDE – NEC Express5800/GT110e-S / Air cooling model
NEC Corporation Revision 5.0 – July 17, 2013 10
Expansion Slots
Legend
#1
PCIe 2.0 x4, x8 connector, Low Profile, up to 167.6mm length
#2
PCIe 2.0 x4, x8 connector, Low Profile, up to 167.6mm length
#3
PCIe 3.0 or 2.0 x16, x16 connector, Low Profile, up to 167.6mm length
#4
32-bit / 33 MHz / 5 V PCI, Low Profile, up to 167.6mm length
NOTE:
 The slot #3 works at PCIe 3.0 speeds on Xeon processor systems.
#4
#3
#2
#1
