NEC Express5800/GT110e-S User Manual

CONFIGRATION GUIDE – NEC Express5800/GT110e-S / Air cooling model
NEC Corporation Revision 5.0 – July 17, 2013 7
External Views
Front View
3.5-inch Drive Model
2.5-inch Drive Model
Legend
A.
Vent Holes Cover
F.
USB Connectors
B.
Power Button
G.
Optical Disk Drive
C.
Power LED
H.
3.5-inch Media Bay
D.
Hard Drive Activity LED
I.
2.5-inch Drive Bay
E.
System Status LED
J.
Drive Bay Cover Key
Rear Views
Leged
A.
Serial Port Connector
F.
Management LAN Connector
B.
VGA Connector
G.
Data LAN Connectors
C.
BMC Reset Switch
H.
PCI Slots (Low Profile)
D.
Dump (NMI) Switch
I.
AC Inlet
E.
USB Connectors
A
B
C
D
E
F
G
H
A
B
C
D
E
F
G
H
I
J
A
B
C
D
E
F
G
H
I

NEC Express5800/GT110e-S Specifications

General

Brand	NEC
Model	Express5800/GT110e-S
Category	Server
Language	English
