CONFIGRATION GUIDE – NEC Express5800/GT110e-S / Air cooling model
NEC Corporation Revision 5.0 – July 17, 2013 3
Technical Specification
Key Features
 Ultra compact form of 93mm in width, 13 liters in volume
 Up to 32 GB of high speed DDR3-1600 memory
 Full manageability by integrated EXPRESSSCOPE Engine 3
 Function in maximum 40° C / 104° F ambient temperature
Specification
3.5-inch Drive Model
Model
GT110e-S
Part Number
N8100-1891F
Processor
Type
Intel® Pentium® processor
G2020
Intel® Xeon® processor
E3-1220 v2
Clock speed
2.90 GHz
3.10 GHz
Number of Processors
1
Cache
3 MB
8 MB
Cores and Threads
2C / 2T
4C / 4T
Chipset
Intel® C204 Chipset
Memory
Type
DDR3-1600 ECC Unbuffered DIMM
Standard Capacity
0 GB
Maximum Capacity
32 GB (4 x 8 GB)
Internal Storage
Standard Capacity
0 GB
Maximum Capacity
8 TB (2 x 4 TB)
Disk Controller
SATA : 6Gb/s (Integrated)
RAID
SATA :
1
RAID 0/1
Hot Plug
-
Optical Disk Drive
DVD-ROM
3.5-inch Media Bays
1
Disk Drive Bays
2
Expansion Slots
Total: 4 slots available
1 PCIe 3.0
2
x16 (x16 connector)
2 PCIe 2.0 x4 (x8 connector)
1 32-bit/33 MHz PCI
Video
Controller (VRAM)
Integrated in Server Management Controller (32MB)
Resolution / Color
1280 x 1024 / 16.7M
3
Interfaces
1 VGA (15-pin mini D-sub,1 rear)
1 to 2 Serial (9-pin mini D-sub, RS232-C, 1 to 2 rear)
8 USB2.0 (2 front, 4 rear, 2 internal)
2 1000BASE-T LAN connector (RJ-45, 2 rear)
1 100BASE-TX LAN connector for Management (RJ-45, 1 rear)
Server Management
EXPRESSSCOPE Engine 3
System Fan
Standard
Power Supply
1 x 250 Watt 80 PLUS® Sliver certified non-Hot plug PSU
100-240 VAC ± 10% 50 / 60 Hz ± 3 Hz
