CONFIGRATION GUIDE – NEC Express5800/GT110e-S / Air cooling model
NEC Corporation Revision 5.0 – July 17, 2013 6
Temperature, Relative Humidity
(non-condensing)
Operating: 10° to 40° C / 50° to 104° F, 20 to 80%
Non-Operating: -10° to 55° C / 14° to 131° F, 20 to 80%
FCC, CE, BSMI, CCC, UL, CB, RoHS, WEEE
Operating Systems and Virtualization
Software
Microsoft® Windows Server® 2003 R2, Standard Edition SP2 or later
Microsoft® Windows Server® 2003 R2, Enterprise Edition SP2 or later
Microsoft® Windows Server® 2008 Standard
Microsoft® Windows Server® 2008 Standard (x64)
Microsoft® Windows Server® 2008 Enterprise
Microsoft® Windows Server® 2008 Enterprise (x64)
Microsoft® Windows Server® 2008 R2 Standard
Microsoft® Windows Server® 2008 R2 Enterprise
Microsoft® Windows Server® 2012 Standard
5
Microsoft® Windows Server® 2012 Datacenter
5
Red Hat Enterprise Linux 5.8 or later
6
Red Hat Enterprise Linux 5.8 or later (EM64T)
6
Red Hat Enterprise Linux 6.2 or later
6
Red Hat Enterprise Linux 6.2 or later (EM64T)
6
VMware ESXi™ 5.0 update 1
7
VMware ESXi™ 5.1
7
1
An optional HDD Cage is required to install more than 3 hard drives. The optional HDD Cage occupies 3.5-inch
media bay.
2
Embedded SATA RAID controller is supported only on Windows operating systems.
3
The PCIe x16 slot works at PCIe 2.0 speeds on Pentium processor systems.
4
Maximum resolution available via EXPRESSSCOPE Engine 3 remote console is 1280 x 1024 / 65K colors.
5
Noise emission was measured at the operator positions in accordance with ISO 7779. The actual value may vary
by the operating environment.
6
For Windows Server 2012 installation, download the driver kit from the following website and install it after OS
installation
http://www.nec.com/en/global/prod/express/download/
7
For Linux support, contact your sales representative or go to the NEC website at:
http://www.nec.com/global/prod/express/linux/index.html
8
VMware ESXi is supported only on Xeon processor systems.
