CONFIGRATION GUIDE – NEC Express5800/GT110e-S / Air cooling model
NEC Corporation Revision 5.0 – July 17, 2013 15
4.2.3 RAID 0/1 Controller with 128 MB Cache
Category
Product Name / Description
Part Number
Storage Controller
Required
RAID Controller (128MB, RAID 0/1)
Promise SuperTrak TX8760T-128
RAID 0/1/10, 128MB, Int. 8, PCIe 2.0(x8), SAS 6Gb/s, SATA
3Gb/s
N8103-128
RAID BBU
Recommended
RAID Battery Backup Unit
for Promise SuperTrak EX8760T
N8103-141
Cable
Required
Internal SATA Cable
mini-SAS to 2x Single SATA
K410-253(00)
HDD Cage
3.5-inch HDD Cage
2 x 3.5-inch non hot plug (fixed) hard drive bays
(Standard)
Drive
2 slots available
500GB 7.2K non-Hot Plug 3.5-inch SATA HDD
1 x 500 GB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-359
1TB 7.2K non-Hot Plug 3.5-inch SATA HDD
1 x 1 TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-360
2TB 7.2K non-Hot Plug 3.5-inch SATA HDD
1 x 2 TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-361
3TB 7.2K non-Hot Plug 3.5-inch SATA HDD
1 x 3TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-362
NOTE:
 All hard drives within a RAID array should be of the same capacity.
4.2.4 RAID 0/1 Controller with 512 MB Cache
Category
Product Name / Description
Part Number
Storage Controller
Required
RAID Controller (512MB, RAID 0/1)
LSI MegaRAID SAS 9267-8i
RAID 0/1, 512 MB, Int. 8, PCIe 2.0(x8), SAS 6Gb/s, SATA 6Gb/s
N8103-149
RAID BBU
Recommended
RAID Battery Backup Unit
for LSI MegaRAID SAS 9267-8i
N8103-155
Cable
Required
Internal SATA Cable
mini-SAS to 2x SATA
K410-253(00)
HDD Cage
3.5-inch HDD Cage
2 x 3.5-inch non hot plug (fixed) hard drive bays
(Standard)
Drive
2 slots available
500GB 7.2K non-Hot Plug 3.5-inch SATA HDD
1 x 500 GB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-359
1TB 7.2K non-Hot Plug 3.5-inch SATA HDD
1 x 1 TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-360
2TB 7.2K non-Hot Plug 3.5-inch SATA HDD
1 x 2 TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-361
3TB 7.2K non-Hot Plug 3.5-inch SATA HDD
1 x 3TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-362
4TB 7.2K non-Hot Plug 3.5-inch SATA HDD
1 x 4 TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-396
NOTE:
 All hard drives within a RAID array should be of the same capacity.
