NEC HT410 - 9 Appendix; Cabinet Dimensions

E-55
Unit = inch/mm
9. APPENDIX
Cabinet Dimensions
9. APPENDIX
PC CONTROL
COMPONENT IN
COMPUTER IN
VIDEO INAUDIO IN
S-VIDEO IN
R
Cr/Pr
Cb/Pb
Y
L
AUDIO IN
AC IN
LAMP
STATUS
POWER
AUTO
ADJ.
ON/STAND BY
SELECT
FOCUS
LENS SHIFT
DOWN
UP
SOURCE
2.07"/52.5
7.36"/187.0
0.33"/8.5 13.27"/337.0
3.11"/79.0
5.24"/133.2
4.4"/113.0
