NEC MultiSync LCD3215 User Manual

English-21
English
Setting Default
BRIGHTNESS Adjusts the overall image and background brightness.
CONTRAST Adjusts the image brightness in relation to the input signal.
NOTE: sRGB picture mode is standard and cannot be changed.
SHARPNESS Adjusts the crispness of the image.
BLACK LEVEL Adjusts the image brightness in relation to the background.
TINT Adjusts the tint of the screen.
INPUT DVD/HD, VIDEO(S), VIDEO only
COLOR Adjusts the color depth of the screen.
INPUT DVD/HD, VIDEO(S), VIDEO only
COLOR TEMPERATURE Color temperature can be selected out of NATIVE, 9300K, USER, 6500K and 5000K.
When USER is selected, R.G.B can be adjusted individually. (RGB 1,2,3 only)
COLOR CONTROL Adjusts the levels of the Red, Green, Blue and Saturation.
INPUT RGB1, 2, 3 only NOTE: It can be adjusted only when USER is selected by COLOR TEMPERATURE.
USER-R Adjusts the level of RED.
USER-G Adjusts the level of GREEN.
USER-B Adjusts the level of BLUE.
GAMMA SELECTION Select a display gamma for best picture quality.
NATIVE Gamma correction is handled by the LCD panel.
2.2 Typical display gamma for use with a PC.
2.4 Good for video (TV, DVD, etc.)
S GAMMA Special gamma for certain types of movies. Raises the dark parts and lowers the light parts
of the image.
NOTE: sRGB picture is standard and cannot be changed.
NOISE REDUCTION Adjusts the amount of noise reduction.
INPUT VIDEO(S), VIDEO only
FILM MODE Selects Film mode function. ( AUTO)
INPUT DVD/HD, VIDEO(S), VIDEO only This mode is better suited for movies, which is converted 24 Frames/sec source to DVD Video.
PICTURE RESET Resets the all settings within the PICTURE menu back to factory setting.
AUTO SETUP Press “SET” button to automatically adjust screen size, horizontal position, vertical position,
INPUT RGB2, 3 only clock, clock phase, white level and black level.
AUTO ADJUST Selecting ON when changing the timing, the horizontal position, vertical position and
INPUT RGB2, 3 only clockphase will adjust automatically.
H POSITION Controls the horizontal position of the image within the Display area of the LCD.
Press + to move right. Press - to move left.
V POSITION Controls the vertical position of the image within the Display area of the LCD.
Press + to move up. Press - to move down.
CLOCK Press + to expand the width of the image on the right of the screen.
INPUT RGB2, 3 only Press - to narrow the width of the image on the left.
CLOCK PHASE Adjusts the visual “noise” on the image.
INPUT RGB2, 3 only
ZOOM MODE You can select “FULL”, “NORMAL”, “DYNAMIC”, “CUSTOM” and “REAL”.
NOTE: DYNAMIC is INPUT DVD/HD, VIDEO(S), VIDEO only.
Selecting DYNAMIC expands 4:3 picture to fill the screen. Some of the image is lost due to
expansion.
Selecting “REAL” image will be displayed 1 by 1pixel.
ADJUST

NEC MultiSync LCD3215 Specifications

General

Pixel pitch	0.511 x 0.511 mm
Aspect ratio	16:9
Response time	9 ms
Display diagonal	32 \
Display resolution	1360 x 768 pixels
Vertical scan range	50 - 85 Hz
Horizontal scan range	31.5 - 91.1 kHz
Contrast ratio (typical)	800:1
Display number of colors	16.78 million colors
Display brightness (typical)	500 cd/m²
Audio input	Yes
DVI-D ports quantity	1
DVI-I ports quantity	0
Product color	Black
Market positioning	-
Panel mounting interface	400 x 200 mm
Power consumption (typical)	115 W
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth (without stand)	133 mm
Width (without stand)	789 mm
Height (without stand)	476.3 mm
Weight (without stand)	13100 g
