NEC MultiSync LCD3215 User Manual

English-30
Specifications - LCD4215
Product Specifications
LCD Module 42"/106.6 cm diagonal
Pixel Pitch: 0.681 mm
Resolution: 1366 x 768 dots
Color: Over 16 million colors (depending on video card used)
Brightness: 500 cd/m
2
(Typ.)
Contrast Ratio: 800:1
Viewing Angle: 89° (typ) @ CR>10
Design View Distance: 1100 mm
Frequency Horizontal: 15.625/15.734 kHz, 31.5 kHz - 91.1 kHz
Vertical: 58.0 - 85.0 Hz
Pixel Clock 25.0 MHz - 162.0 MHz
Viewable Size 930.25 x 523.01 mm
Input Signal
RGB1 DVI-D 24pin Digital RGB DVI (HDCP)
VGA60, SVGA60, XGA60, WXGA60, SXGA60*
1
, UXGA60*
1
RGB2 15pin Mini D-sub Analog RGB 0.7 Vp-p/75 ohm
VGA60, SVGA60, XGA60, WXGA60, SXGA60*
1
, UXGA60*
1
Sync Separate: TTL level (Pos./Neg.)
RGB3 BNC (R,G,B,H,V) Analog RGB 0.7 Vp-p/75 ohm
VGA60, SVGA60, XGA60, WXGA60, SXGA60*
1
, UXGA60*
1
Sync Separate: TTL level (Pos./Neg.)
DVD/HD BNC (Y, Cb/Pb, Cr/Pr) Component Y : 1.0 Vp-p/75ohm, Cb/Cr (Pb/Pr) : 0.7 Vp-p/75 ohm
HDTV/DVD: 720p@50Hz/60Hz, 576p@50Hz, 480p@60Hz, 576i@50Hz, 480i@60Hz
VIDEO(S) Mini DIN 4 pin S-VIDEO Y: 1.0 Vp-p/75 ohm C: 0.286 Vp-p/75 ohm (NTSC), 0.3 Vp-p/75 ohm (PAL/SECAM)
NTSC/PAL/SECAM/4.43NTSC/PAL60
VIDEO BNC Composite 1.0 Vp-p/75 ohm
RCA NTSC/PAL/SECAM/4.43NTSC/PAL60
Output Signal
RGB 15pin Mini D-sub Analog RGB 0.7 Vp-p with 75 ohm terminated
Separate HV sync: TTL level (Posi / Nega)
VIDEO BNC Composite 1.0 Vp-p with 75 ohm terminated
AUDIO
AUDIO RCA (L/R) X2 Analog Audio Stereo L/R 0.5 Vrms
Input STEREO Mini Jack
AUDIO STEREO Mini Jack Analog Audio Stereo L/R 0.5 Vrms
Output
Speaker Output External Speaker Jack 7 W + 7 W (8 ohm)
Control RS-232C In: 9 Pin D-sub
Power Supply 3.4 - 1.35 A @ 100-240VAC, 50/60Hz
Operational Environment Temperature: 5 - 40°C (landscape), 5 - 35°C (portrait)
Humidity: 20 - 80% (without condensation)
Altitude: 0 - 3000 m
Storage Environment Temperature: -20 - 60°C
Humidity: 10 - 90% (without condensation)/ 90% - 3.5% x (Temp - 40°C) regarding over 40°C
Dimension Net: 1022.9 (W) x 613.5 (H) x 133 (D) mm (without stand)
Gross: 1175 (W) x 774 (H) x 283 (D) mm
Weight (Without stand) Net: 20.5 Kg
Gross: 47.1 Kg
VESA compatible arm mounting interface 200 mm x 200 mm (4 Holes)
Complied Regulatory and Guidelines UL60950-1/CSA C22.2 No.60950-1/ TUV-GS/EN60950-1
FCC-B/DOC-B/EN55022-B/EN55024/EN61000-3-2/EN61000-3-3/CE/GOST-R
Power Management VESA DPM
Plug & Play VESA DDC2B, DDC/CI
Accessories Setup manual, Power Cord, Video Signal Cable, Remote Control, AAA Battery x 2, Clamp x 2,
Screw for Main switch cover x 2, Screw for Clamp x 2, CD-ROM, Thumbscrew for stand x 2,
Main switch cover
NOTE: Technical specifications are subject to change without notice. *1: Compressed image

NEC MultiSync LCD3215 Specifications

General

Pixel pitch	0.511 x 0.511 mm
Aspect ratio	16:9
Response time	9 ms
Display diagonal	32 \
Display resolution	1360 x 768 pixels
Vertical scan range	50 - 85 Hz
Horizontal scan range	31.5 - 91.1 kHz
Contrast ratio (typical)	800:1
Display number of colors	16.78 million colors
Display brightness (typical)	500 cd/m²
Audio input	Yes
DVI-D ports quantity	1
DVI-I ports quantity	0
Product color	Black
Market positioning	-
Panel mounting interface	400 x 200 mm
Power consumption (typical)	115 W
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth (without stand)	133 mm
Width (without stand)	789 mm
Height (without stand)	476.3 mm
Weight (without stand)	13100 g
