NEC MultiSync LCD3215 User Manual

English-22
CUSTOM ZOOM “CUSTOM ZOOM” will be selected when you select “CUSTOM” on the screen “ZOOM” mode.
ZOOM Expands the horizontal and the vertical size simultaneously.
H ZOOM Expands the horizontal size only.
V ZOOM Expands the vertical size only.
H POS Moves to the right with + button. Moves to the left with - button.
V POS Moves up with + button. Moves down with - button.
H RESOLUTION Adjusts the horizontal size of the image.
INPUT RGB1, 2, 3 only Press + button to expand, and press - button to narrow the width of the image on the screen.
V RESOLUTION Adjusts the vertical size of the image.
INPUT RGB1, 2, 3 only Press + button to expand, and press - button to narrow the width of the image on the screen.
INPUT RESOLUTION Selects to decision of input signal timings 1024x768, 1280x768 and 1360x768, if there is a
INPUT RGB2, 3 only detection problem.
If no problem is detected, the only available option will be “AUTO”.
ADJUST RESET Resets the all settings within the ADJUST menu back to factory setting.
BALANCE Adjust the balance of L/R volume.
TREBLE To accentuate or reduce the high frequency sound. Press + to increase, press - to decrease.
BASS To accentuate or reduce the low frequency sound. Press + to increase, press - to decrease.
AUDIO RESET Resets the all settings within the AUDIO menu back to factory setting.
OFF TIMER Sets the monitor to power off after a length of time.
A time between 1 to 24 hours is available.
SCHEDULE Creates a working schedule for the monitor to use. This OSD can’t remove except EXIT.
(See “NOTE 1” on page 25 for further information).
DATE AND TIME Sets the date, time, and daylight saving region.
Setting item: YEAR/MONTH/DAY/HOUR/MINUTE/DAYLIGHT SAVING TIME
Date & time must be set in order for the “SCHEDULE” function to operate.
SCHEDULE RESET Resets the all settings within the AUDIO menu back to factory setting except DATE AND
TIME setting.
PIP SIZE Selects the size of sub-picture used in “Picture-in-Picture” (PIP) mode.
“Large”, “Middle” and “Small” are available.
PIP AUDIO Selects the sound source in PIP mode.
PIP RESET Resets the all settings within the PIP menu back to factory setting.
LANGUAGE Selects the language used by the OSD from seven languages.
ENGLISH/DEUTSCH/FRANÇAIS/ESPAÑOL/ITALIANO/SVENSKA/
OSD TURN OFF Turns off the OSD after a period of inactivity. The preset choices are 5 - 120 seconds.
OSD V-POSITION Adjusts the vertical position of the OSD menu.
OSD H-POSITION Adjusts the horizontal position of the OSD menu.
INFORMATION OSD Selects the information OSD displays or not. The information OSD will display when input signal
or source change or warning message like as no-signal or out-of range.
A time between 1 to 10 seconds is available.
MONITOR INFORMATION Indicates the model and serial number of your monitor.
OSD RESET Resets the all settings within the OSD menu back to factory setting.
PIP
OSD
AUDIO
SCHEDULE

NEC MultiSync LCD3215 Specifications

General

Pixel pitch	0.511 x 0.511 mm
Aspect ratio	16:9
Response time	9 ms
Display diagonal	32 \
Display resolution	1360 x 768 pixels
Vertical scan range	50 - 85 Hz
Horizontal scan range	31.5 - 91.1 kHz
Contrast ratio (typical)	800:1
Display number of colors	16.78 million colors
Display brightness (typical)	500 cd/m²
Audio input	Yes
DVI-D ports quantity	1
DVI-I ports quantity	0
Product color	Black
Market positioning	-
Panel mounting interface	400 x 200 mm
Power consumption (typical)	115 W
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth (without stand)	133 mm
Width (without stand)	789 mm
Height (without stand)	476.3 mm
Weight (without stand)	13100 g
