NEC NP-PX800X Installation And Assembly

2 of 8
ISSUED: 09-15-11 SHEET #:125-9244-1
A
NOTE: Readentireinstructionsheetbeforeyoustartinstallationandassembly.
Beforeyoustartmakesureallpartslistedareincludedwithyourproduct.
B C D
E F G
H I
J
K
L
M
N
R
Description Qty. Part #
A adapterassembly 1 056-1061
B M4x12mmsocketpinserratedwasherheadscrew 4 510-1079
C M5x10mmsocketpinserratedwasherheadscrew 4 510-1126
D M4x40mmsocketpinserratedwasherheadscrew 2 510-1091
E 4mmallenwrench 1 560-9646
F .375spacer 2 590-1140
G .75spacer 2 590-1300
H projectormountassembly 1
055-1950
I columnconnector 1 580-1025
J
ceilingplate 1
580-1042
K
.25"x.5"x.25"spacer
2 590-1050
L
#10-32x3/8"thumbscrew
1 560-1107
M
#10-32x3/8"socketpinserratedwasherheadscrew
1 520-1151
N
10-32x3/8"slottedsetscrew
3 520-1187
O
concreteanchor
2 590-0320
P
#10-32x3/8"socketpinscrew
2 520-1084
Q
#14x2.5"woodscrew
2 5S1-015-C03
R
5mmallenwrench
1 560-0216
S
M5x10mmtype-Fscrew
1 520-1164
Parts List
P
Q
O
S
