NEC NP-PX800X Installation And Assembly

5 of 8
ISSUED: 09-15-11 SHEET #:125-9244-1
Handthreadprojectormountassembly(H)intoceilingplate(J)asshowningure2.1.Alignthenotchofprojector
mountassemblywithoneofthefourholesinceilingplate(J)andsecurewithanM5x10mmsocketpinscrew(S)
asshownindetail1.
NOTE:Slottedsetscrew(N)isusedtojamagainstthethreadsoftheprojectormountassemblytopreventany
excessmovementoftheprojectormountassembly(H).Donotovertightenscrew;overtighteningscrewwilldamage
threadsmakingitdifculttoseparateprojectormountassemblyfromceilingplate.
Flush Mount Installation
2
g. 2.1
DETAIL 1
J
S
N
H
NOTCH
