1. Introduction
About this user’s manual
Thefastestwaytogetstartedistotakeyourtimeanddoeverythingrightthersttime.Takeafewminutesnowto
reviewtheuser’smanual.Thismaysaveyoutimelateron.Atthebeginningofeachsectionofthemanualyou’llnd
anoverview.Ifthesectiondoesn’tapply,youcanskipit.
NotationbyMainFunctions
Theseindicatethedescriptionsofthemodelgroupsaccordingtothemainfunctions.
[HDBaseT Models]
ApplicabletomodelsNP-PA622U/NP-PA522U/NP-PA672W/NP-PA572W/NP-PA722X/NP-PA622X.
[MM Models]
ApplicabletomodelsNP-PA621U/NP-PA521U/NP-PA671W/NP-PA571W/NP-PA721X/NP-PA621X.
*Thedescriptionappliestoallmodelsifthemodelnameisnotindicated.
NotationbyResolution
Theseindicatethedescriptionsofthemodelgroupsaccordingtotheresolutionoftheliquidcrystalpanels.
WUXGAType
ApplicabletomodelsNP-PA622U/NP-PA621U/NP-PA522U/NP-PA521U.
WXGAType
ApplicabletomodelsNP-PA672W/NP-PA671W/NP-PA572W/NP-PA571W.
XGAType
ApplicabletomodelsNP-PA722X/NP-PA721X/NP-PA622X/NP-PA621X.
*Thedescriptionappliestoallmodelsifthetypenameisnotindicated.
How to Differentiate the Model Group
PA622 U

“1”referstoaMMmodel.
“2”referstoaHDBaseTmodel.
HowtoDifferentiatetheTypeGroup
PA622U

“U”referstoaWUXGAtype.
“W”referstoaWXGAtype.
“X”referstoaXGAtype.
ModelNameSymbol
Example:PA622U
“NP-”isnotindicatedontopofthecabinet.
