48
4. Using the Viewer
Parts of each screen
The Viewer has four screens.
(1) Viewer start screen (3) Thumbnail screen (9) Slide screen/
(11) Slideshow screen
Name Description
(1)Viewerstartscreen ThisscreenwillbedisplayedrstwhenyouselecttheViewer.
(2)USBicon ThisiconindicatesthattheUSBmemoryisinsertedintotheprojector.
(3)Thumbnailscreen ThisscreenwillshowalistoffoldersandimagelesstoredintheUSBmemory.The
JPEGExifleswillbedisplayedinthumbnailscreenonly.
• Themaximumnumberofimagelesorfolderswithinonepageisdifferentdepend-
ingonthemodel.
 P554U/P474U/P554W/P474Ware(6×4lateralbylongitudinal)
 P604X/P603X/PE523Xare(5×4lateralbylongitudinal)
(4)Cursor
Thecursorisusedtoselect(highlight)thefolderorimagelebyusing▲▼◀▶ button.
(5)Backicon Thisiconisusedtoreturntotheupper(parent)folder.
(6)Foldericon ThisiconshowsthattheUSBmemoryhasfolders.
(7)Pageup(Pagedown)
icon
Thisiconshowsfurtherfoldersorimagelesareavailableinthenext(previous)page.
Use the ▶buttontogotothenext(previous)row.ThePAGE▽orPAGE△ on the
remotecontrolisusedtogotothenextorpreviouspagedirectly.
(8)Thumbnailtoolbar Thistoolbarisusedinthethumbnailscreen.PressingtheMENUbuttonwilldisplay
thistoolbar.(→page49)
(9)Slidescreen Thisscreenisusedformanualplayback.Theselectedimagewillbedisplayedinfull
screen.
(10)Slidetoolbar Thistoolbarisusedintheslidescreen.PressingtheMENUbuttonwilldisplaythis
toolbar.(→page50)
(11)Slideshowscreen Thisscreenisusedforautoplayback.Theslideswillbechangedautomatically.
(12)Slideshowtoolbar Thistoolbarisusedintheslideshowscreen.PressingtheMENUbuttonwilldisplay
thistoolbar.(→page50)
(5) (6) (4) (7)
(8)(2) (10) (12)
