NEC SV9100 Setup Guide

SV9100 Dialer Setup Guide (Multiline Telephone) iii
LIST OF FIGURES AND TABLES
Figure 2-1 Multiline Telephone application showing “Online” Status for the extension ............2-5
Figure 2-2 Manual Configuration of the PBX Server and Proxy ...............................................2-6
Table 2-1 Account Provisioning Parameters in the UT880 Dialer Phone App ........................2-7
Figure 2-3 Account Management - Set as Default and Delete .................................................2-8
Figure 2-4 Multiline Telephone Application Status Notification Area ........................................2-9
Figure 2-5 Multiline Telephone Application Menu ...................................................................2-10
Figure 2-6 Multiline Telephone Application Menu ...................................................................2-10
Figure 2-7 Opening Contacts from the UT880 NMLT Multiline Telephone Application ..........2-11
Figure 2-8 The Multiline Telephone Application Screen .........................................................2-12
Figure 2-9 Dialer LED Function Emulation .............................................................................2-12
Figure 2-10 Call Logs In the Multiline Telephone Application ...................................................2-13
Figure 2-11 UC Suite Application .............................................................................................2-14
Figure 2-12 UC Suite Dial Screen ............................................................................................2-15
Figure 2-13 Feature Options Menu and Software Information Screen .....................................2-16

NEC SV9100 Specifications

General

Unified Messaging	Yes
VoIP Support	Yes
SIP Support	Yes
VoIP Protocols	SIP, H.323
Mobility	Yes
Type	IP-PBX
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	0°C to 40°C (32°F to 104°F)
Humidity	10% to 90% (non-condensing)
System Type	Hybrid (Supports Analog, Digital, and IP)
