Audio input settings
Audio input settings are used to adjust settings like input gain, enable mixer function and wake on
signal settings.
All commands start with: NEUNIT=<A>,SETTINGS=INPUT,INPUT=<B>,
Where <A> is the unit ID, default 1 and <B> is the number of the INPUT you want to congure.
All commands must end with a \CR.
Description: Syntax <X> Default <X> R/W
Set analog input gain for input 1 to 4. GAIN=<X> -12 to +12 0 R/W
Activate mixer function for input 1.
Note: Only works for <B> = 1
MIX=<X> TRUE or
FALSE
FALSE R/W
Activate wake on signal at the input. WOS=<X> ON OR OFF OFF R/W
Set wake on signal trigger level for input
1 to 4.
Note: Only works for <B> = 1, 2, 3 or 4
LEVEL=<X> -70 to -30 -50 R/W
Set wake on signal time out for input 1
to 4.
Note: Only works for <B> = 1, 2, 3 or 4
OFFDELAY=<X> -70 to -30 -50 R/W
Examples of use:
- NEUNIT=1,SETTINGS=INPUT,INPUT=2,ENABLED=FALSE\CR <- Disables input 2.
- NEUNIT=1,SETTINGS=INPUT,INPUT=4,GAIN=+9\CR <- Sets input gain on input 4 to +9 dB.
- NEUNIT=1,SETTINGS=INPUT,INPUT=1,MIX=TRUE\CR <- Activates the mixer function on
input 1.
- NEUNIT=1,SETTINGS= INPUT,INPUT=3,WOS=ON\CR <- Enables wake on signal on input 3.
- NEUNIT=1,SETTINGS= INPUT,INPUT=1,LEVEL=-42\CR <- Sets the wake on signal trigger
level to -42 dB on input 1.
