Audio output settings
Audio output settings adjust amplier output parameters such as equalizer settings, balance, and
output power limit etc.
All commands start with: NEUNIT=<A>,SETTINGS=OUTPUT,
Where <A> is the unit ID, default 1. All commands must end with a \CR
Description: Syntax <X> Default <X> R/W
Set low band equalizer level. POWER=<X> ON or OFF OFF R/W
Select audio input. INPUT=<X> 1 to 5 1 R/W
Set output volume. VOL=<X> -70 to +12 -50 R/W
Set output volume for input 1 in mix
mode.
MIXVOL=<X> -70 to +12 -50 R/W
Mute audio output from input 1 in mix
mode on or off.
MIXMUTE=<X> ON or OFF OFF R/W
Unit, SN UNITSN=<X> xxyyzzzzz R
Examples of use:
- NEUNIT=1,SETTINGS=OUTPUT,LOW=+5\CR <- Sets low band equalizer to +5 dB.
- NEUNIT=1,SETTINGS=OUTPUT,HIGH=-3\CR <- Sets high band equalizer to -3 dB.
- NEUNIT=1,SETTINGS=OUTPUT,BALANCE=-10\CR <- Sets balance of left channel to -10 dB.
I/O settings
I/O settings can be controlled by the following commands.
All commands start with: NEUNIT=<A>,SETTINGS=IO,IO=<B>,
Where <A> is the unit ID, default 1 and <B> is the number of the IO you want to congure. All
commands must end with a \CR.
Description: Syntax <X> Default <X> R/W
Set the I/O function
See page 18 for description of the IO
function.
FUNCTION=<X> INPUT, OUTPUT INPUT R/W
Example of use:
- NEUNIT=1,SETTINGS=IO,IO=2,FUNCTION=OUTPUT\CR <- Sets IO 2 to output.
