7 Exploded Drawings & Parts List
7.1 Parts List
Item Number
PART NUMBER
QTY
DESCRIPTION
1
502-001-261
1
FOOT
2
504-001-056
2
8mm x 110mm LEG ASM - NS-40
3
511-001-131
1
SPARK SHIELD
4
524-005-003
1
SCREW,M4X6 FPSS
5
524-005-007
2
SCREW,M8X8 FPSS
6
524-005-097
4
SCREW,M5X5 FPSS ZINC DIN913
7
524-005-100
3
SCREW,M4X16 OHMS ZINC
8
524-005-101
2
SCREW,M5X16 FHSC ZINC
9
524-005-103
1
SCREW,M3X5 LHS DIN7984
10
524-005-104
1
NUT M5 THICK
11
524-005-105
1
SCREW,M5X10 SHC DIN912
12
526-001-233
1
SPRING,COMPRESSION
13
526-001-234
1
SPRING,MAIN,NCD GAP GUN (Factory Installed)
14
526-001-235
1
SPRING,LIFTING RING
15
526-001-268
1
SPRING,MAIN,NCD GAP GUN HEAVY CONTACT (Not
Installed)
16
713-032-000
4
SPLICE,WIRE,#16-20
17
720-517-000
1
WELD CABLE JUMPER
18
720-519-081
1
WELD CABLE ASM
19
721-268-010
1
CONTROL CABLE ASM
20
726-013-002
1
COLLET
21
729-023-017
1
WASHER 5mm CONICAL SPRING
22
751-003-029
1
DUST BELLOWS
23
751-458-016
1
LIFTING RING
