Nelson NCD+ Auto-Gap Gun - Specifications

© 2016 Nelson Stud Welding, Inc. Page 26
All Rights Reserved. February 2016 Part No. 729-110-042 v1.03
Technical Specifications
8.2 Specifications
NCD+™ Auto-Gap Gun
Min.
Max.
Gap Spring Pressure Range (lbs)
4
7
Contact Spring Pressure Range (lbs)
7
15
Standard Spring Weld Mode
Auto-Gap
Gap Mechanism
Floating Lift Solenoid Device
Pressure Control
Stepless Nut Adjustment
Gap Control
Stepless Screw Adjustment
Front Ends
Adjustable, Tripod, Spark Shield
Max Stud Length
Depends on Accessories
Dimensions without Cable
7-1/4” x 1-1/2” x 5-1/2”
(184 mm x 38 mm x 140 mm)
Weight without Cable
2.2 lb. (1 kg) Max
Cable Length
20 ft. (2.7 m)
Control Cable Connector
12 Pin Binder
Power Cable Connector
Medium Size Dinse
Maximum Gap
0.197 in (5 mm), floating lift
Stud Capacity (max)
1/4" flanged (NCD+ 1000),
5/16” unflanged (NCD+ 1600),
3/8” (NCD+ 3200)
Storage Temperature (°C)
-5°C to 50°C (23°F - 122°F)
Operating Temperature (°C)
0°C to 40°C (32°F - 104°F)
IP Rating
20
Stud Placement Tolerances
+/- 0.010 (0.25 mm)
