Nelson RainTrain2 - Controls; Control Identification

Controls
8
Figure 1. Rear of the machine with
the cover open.
Figure 3. Front left-hand corner view
of the machine with cover closed.
Figure 2. Left side view of machine
with the cover open.
Speed Control
Knob
Drum Disengage Mechanism
On/Off Valve
Control Rod
Sprinkler Arc Adjustment Clips
