Nemaxx 330 - SEAT MOUNTING; INFLATE; VALVES AND OPERATION

[
EN ● 11
]
Version: 1.2
KEN002ZB 02.02.2020
A
C
B
A - Paddle
B - Bottom plates
C - side prole (side joiner)
● SEAT MOUNTING
●INFLATE
7. Pump up the keel a little to lift the bottom plates off the floor.
8. Position the side joiners between the rubber stops
Theseatmustbettedbeforetheboatisfullyinated
Inatetheboataboutthree-quartersandinserttheseat.Theninatetheboatfully.
Valves
Theinatablevalvesarespeciallydesignedforsafeandcomfortableuse.Thevalvesareattoincrease
comfort in the boat and prevent damage to the boat.
Make sure the valve is tightly closed before using the boat.
Operating the valve:
● Remove the outer cap. The valve is closed when the middle propeller is in the upper position.
● To open the valve, press the valve bar once.
● To close the valve, press the valve stem again.
