EN 7
]
Version: 1.2
KEN002ZB 02.02.2020
Model Size Max. Load
Capacity
Tube Dia. Number of air
chambers
Max. Power
kW / HP
Max. Load kg Max.
Person
330 3.30 m x 1.50 m 505 kg 42 cm 3 + 1 11 / 15 505 4+1
●TYPE PLATE
TYPE PLATE NEMAXX 330
NOTE: The type plate is located on the inside of the boat mirror.
a) Design category - see Table 1
b) Model number
c) Maximum number of persons (adults + children)
d) Maximum payload: persons + outboard engine + fuel tank + equipment
e) Maximum outboard engine power
f) Air chamber pressure
g) CIN-CraftIdenticationNumber
h) Manufacturer (name and address)
i) Country of origin
●TECHNICAL DATA
a
b
c
d
e
f
g
h
i
PRODUCT INFORMATION
