Neolt Neofold HS 920 - General Information; Machine Structure

Chapter
GENERAL INFORMATION
NEOFOLD HS
VERSION: NF.HS-07-03/2015-GB 1-6
Structure of the machine 1.11.3
The machine includes the following parts:
A Feeding table.
B Right protection.
C left protection.
D Emergency button.
E Top protection.
F Rear protectrion.
G Electronic boards protection.
H Feeding guide.
I Front basket
L Back basket.
M Table
N Main switch.
O Power soket.
P Fuse holder compartment.
Q Keyboard.
R Switch for selection of back or
front sheet ejection.
Front view
C
B
Back view Detail
Keyboard
M
A
H
D
E
G
I
L
Q
Detail
O
P
N
R
F
