Chapter
USE
NEOFOLD HS
VERSION: NF.HS-07-03/2015-GB 6-6
Paper jam or blocking of the machine
6.1.5
In case of sheet jamming or blocking of the machine, immediately interrupt any
operation pressing the emergency button (
B) - (Fig. 6.8) .
After checking the sheet feeding area, rotate the emergency key clockwise (
B) and
then press the sheet eject key. (
2) (Fig. 6.9).
If the sheet is still jammed in the machine, switch the machine off to disengage the
contact of the frictions on the driving rollers, disconnect power cable and try to pull out
the sheet by pulling in the direction opposite to the feeding direction.
Fig. 6.8 Fig. 6.9
190
210
B
2
