Chapter
INSTALLATION
NEOFOLD HS
VERSION: NF.HS-07-03/2015-GB 5-1
Qualifications of the operator 5.1
The transportation, installation and connecting operations of the machine must be carried
out by qualified personnel only, transporters and electricians.
Transportation 5.2
Transportation conditions 5.2.1
The sheet folder is shipped in a carton box (
A) which contains the different components of
the machine. Each component is protected with carton sheets.
Sheet folder (
B). Right shoulder of the stand (C). Left shoulder of the stand (D). Cross
bars (
E). Machine work table (F). Sheet collection basket (G). The box contains the
user’s manual and the tool bag (
H) to carry out the few installation operations of the
machine.
The sizes of the box (carton + pallet) and its total weight (box plus sheet folder) are as
follows:
920 1250
Dimensions (cm)
(inch)
165x75xh70
65”x29,5”xh27,5”
195x75xh70
76,8”x29,5”xh27,5”
Weight (gross - kg)
(Lbs.)
167 kg
(368.2 lib.)
0 Kg
(0 lib.)
The hoisting, transportation and moving operations of the machine or any of its parts must
be performed only by competent and properly trained personnel.
It is absolutely forbidden to pass or stand under hanging loads.
The means used for hoisting, transporting and moving the machine must be adequate to
the weight and composition of the elements to lift, transport and move and must comply
with the laws in force in the country of use.
Protect the machine from external atmospherics, see paragraph Characteristics of the
place the machine is placed in 5.5.1.
