SAFETY INFORMATION
NEOFOLD HS
VERSION: NF.HS-07-03/2015-GB 2-4
Sensory presence paper 2.3.3
 Five photoelectric cells (F1-F2-F3-F4-F5) signal the presence of the paper.
conveyor
Rear panel
Idle feed roller
Minor fold roller
F5
Electronic cards
board
Feed roller
Main roller
F3 – F4
F2
(190)
F1
(210)
Top panel
