Neolt Neofold HS 920 - Machine Characteristics; Working Space Requirements

Chapter
CHARACTERISTICS OF THE MACHINE
NEOFOLD HS
VERSION: NF.HS-07-03/2015-GB 3-2
Work space 3.1.1
Make sure the machine is installed so that there is enough space for ordinary and
extraordinary maintenance operations and for the proper use of the machine, thus taking
into account the minimum space between the moving parts (media being worked or
machine), the fixed elements (walls or the room where the machine is installed), in
compliance with the table of the UNI EN 349:1995 standards (attachment A).
Part of the body Minimum space Figure
Body
500 mm
(19,7”)
Head
(Less favourable position)
300 mm
(11,8”)
Leg
180 mm
(7,1”)
Foot
120 mm
(4,7”)
Toe of foot
50 mm
(1,97”)
Arm
120 mm
(4,7”)
Hand
Wrist
Fist
100 mm
(3,9”)
Finger of hand
25 mm
(0,98”)
