THE SEAT POST MUST NOT BE PULLED OUT ABOVE THE ENGRAVED SAFETY MARK (VERTICAL BARS).
The minimum height between the upper surface of the saddle and the ground is 78 cm.
1.2 Handlebar adjustment:
Allen key 6 mm
To be comfortable, the position of your handlebars should be at least at the same height as your saddle, or
more depending on your comfort. Unscrew the Allen screw and set the desired height of your handlebar.
Be careful to tighten the quick hitch tie fully before using your bike.
To adjust the tilt, use an Allen wrench to loosen the 4 screws on the stem.
After adjusting, firmly re-tighten the screw, with tightening torque max: 19.6Nm.
