N21

Hardware User Guide

Memory

RAM: 32 Mb

ROM: 32 Mb

Band

B3, B5, B8, B20, B28

Wireless rate

LTE Cat NB1: 32 kbit/s (DL) /72 kbit/s (UL)

Transmit power

LTE: +23 dBm+/-2 dBm (Power Class 3)

Application interfaces

4G antenna, 50 Ω characteristic impedance

1 UART interface, used to send AT commands

1 USIM interface, compatible with 1.8V/3V USIM card

2*2 mm embedded eSIM (Optional)

AT commands

3GPP Rel-13

Neoway extended commands

Protocol

TCP, UDP, HTTP, HTTPS, FTP, LWM2M, MQTT, COAP

Certificates

and

Approvals

CCC, SRRC, CTA, RoHS, CE*, GCF*, Vodafone*, FCC*

China Mobile/China Unicom/China Telecom

Ali cloud*

* indicates in development
