Neptune Technology R900 Installation Supplement

Page 18
UPS Specifications
AC Input Voltage
90V-305Vac
AC Input Frequency
47/63 Hz
Input Plug Type
3 prong grounded
Input Cable Length
12'
DC output Power
150 Watts
DC Output Voltage
45-50V
DC output Connector
2 position screw terminal
Alarms
Battery On, Battery Low, Battery Fail, Battery
Missing
Battery Type
Lead acid
Model
GS Battery PYL12V80TT
Capacity
80Ah
Physical Dimensions
16”H x 12”W x 8”D (in./approx)
Weight
75 lbs
Power Cable
12AWG
Alarms
Cat-5 connection
Mounting Options
Wall or pole mount
Operating Temperature
(-)40°C to +55°C ( -40°F to + 131°F)
Operating Humidity
0% to 95% non condensing
Safety Spec
EN-60950-1, EN-60950-2
Emissions Certification
FCC 47 CFR Part 15 Class B

Neptune Technology R900 Specifications

General

Brand	Neptune Technology
Model	R900
Category	Gateway
Language	English
