Page 19
PoE Injector Specifications
Data rates
10/100/1000 Mbps
PoE Output Power
60W @ 50-57VDC
PoE pin assignment
4/5 (+), 7/8 (), 1/2(), 3/6(+)
Standards Compliance
IEEE 802.3af (PoE, PoH Type1) IEEE 802.3at (PoE+
including 2-event, PoH Type 2), RoHS Compliant,
WEEE Compliant, CE
DC Input Power
36 to 60 VDC
Dimensions
214 mm x 150 mm x 70 mm (8.42 in. x 5.90 in. x
2.75 in)
Weight
1.65 lbs
Connectors
Shielded rugged RJ-45 with gasket
Operating Temperature
(-)40º to 122ºF (-40 to 50ºC) for 60W -40º to
131ºF (-40 to 55ºC) for 30W
Storage Temperature
40º to 185ºF (40º to 85ºC)
Operating and Storage
Humidity
Maximum 95% non-condensing
Operating Altitude
Up to 6,560 ft. (2000 m)
Weather Rating
IP66, NEMA 4X
