Neptune E-CODER Quick Install Guide

8
Programming the HI Register
To complete the following steps, use the Neptune field
programmer to select the ProRead Program tab for
programming.
Figure 17 HI Register
Programming the LO Register
To complete the following steps, use the Neptune field
programmer to select the ProRead Program tab for
programming.
Figure 18 LO Register
1 Select RF Compound HI
format.
2 Match the Connectivity
2W.
3 Match the Dial Code 65.
4 Type the appropriate
register ID.
5 Program the register.
6 Read or query the register to
confirm correct
programming. See
Figure 17.
1 Select RF Compound LO
format.
2 Match the Connectivity 2W.
3 Match the Dial Code 65.
4 Type the appropriate register
ID.
5 Program the register.
6 Read or query the register to
confirm correct
programming. See
Figure 18.

Neptune E-CODER Specifications

General

Output	Digital
Power Source	Battery or external power
Operating Temperature	-20°C to 60°C (-4°F to 140°F)
Power Supply	3.6V Lithium Battery
Dimensions	Varies depending on model
Weight	Varies depending on model
