Neptune E-CODER Quick Install Guide

3
Figure 4 Routing the Wire
Figure 5 Applying Compound
Figure 6 Placing Cover on Register
5 Route the wire as shown in
Figure 4.
6 Apply Novagard G661 or
Dow Corning
®
Compound
#4 to the terminal screws
and exposed bare wires.
See Figure 5.
Neptune recommends Novaguard G661 or Dow
Corning Compound #4.
Novagard may cause irritation to eyes and skin.
If swallowed, do not induce vomiting; dilute
with one to two glasses of water or milk and
seek medical attention. Please refer to:
• MSDS Novagard Silicone Compounds &
Grease Inc. 5109 Hamilton Ave. Cleveland,
OH 44114, 216-881-3890.
• For copies of MSDS sheets, please
call Neptune’s Customer Support
at (800) 647-4832.
7 Place terminal cover on the
register, ensuring wire is
routed through strain relief.
See Figure 6.

Neptune E-CODER Specifications

General

Output	Digital
Power Source	Battery or external power
Operating Temperature	-20°C to 60°C (-4°F to 140°F)
Power Supply	3.6V Lithium Battery
Dimensions	Varies depending on model
Weight	Varies depending on model
