Nespresso Gemini CS220 - Wall Mounting

Towerservicemanual
22
I N S T A L L A T I O N
3.1.2 Wallmounting
Theautomaticcapsuledispensercanbeusedasasingleunithangingonthewall.A
specialwallsupportisneededforfastening.
Considerationsforlocatingtheautomaticcapsuledispenser
• Anearbywallsocket.
• Enoughspaceforthehandlingofthecapsuletubesattheleftsidedooroftheauto
maticcapsuledispenser.
Twopersonsarenecessaryforwallmounting.
Cartoncontentofwallsupportset(NNSAart.no.30034)
1. Checkthewallforhiddenpipesorcableswithametalldetector.
2. Positionsupport(1)onthewallandcheckthatitisinlevel.
3. Markdrillholes(4x)onthewallwiththehelpofthesupport.
4. Drillholesandinsertanchors.
5. Screwsupportonwall(2).
Theautomaticcap
suledispensercan
crashdowncausinginju
riesandmaterialdamage
ifnotmountedonthe
wallproperly.
Checkifdelivered
anchorsarefittingto
thetypeofwalland
replaceifnecessary(e.g.
forgypsumplasterboard).
Thegrossweightofthe
automaticcapsuledis
penserisabout20kg.
Pcs. Designation
1 Wallsupport
2 Sheetmetalscrews,dia.3.5x8mm
4 Plasticanchors
4 Screwswithplainwashers foranchors
4 Plainwashers
Iftheautomaticcap
suledispenser
hangsoutofperpendic
ular,coffeecapsulescan
getcaughtcausingamal
function.
