Nespresso Gemini CS220 - Payment System; Coiner Installation

Towerservicemanual
37
I N S T A L L A T I O N
BRITAAquaQuell1.5
Thistypeofwaterfilterisinstalledontherearsideofthebasecabinet.
3.3 Paymentsystem
Theautomaticcapsuledispensercanbeorderedwithorwithoutcardreader,whereas
thebasecabinetisdeliveredwithoutcoineronly.Thebasecabinetcanbeorderedwith
orwithoutpreinstalledequipmentforacoiner.
3.3.1 Coinerinstallation
Thecoinerhastobeconfiguredfortheappropriatecoinsofthenationalcurrencyin
advanceandbuiltinonsitebyaservicetechnician.
Besidethestandardmountinginthebasecabinet,thecoinercanbeattached
totheautomaticcapsuledispenserwithanoptionalbox.
Thedirectwatercon
nection(1)isshown
assymbolicdrawing
only.Fordetailsrefertothe
installationguideforthe
directwaterconnection.
Foralistofrecom
mendedcoinersrefer
topage19.
