Nespresso Gemini CS220 - Page 44

Towerservicemanual
44
I N S T A L L A T I O N
CS220PROolddriptrays
1. Drillahole(7mmdia)intheleftandrightdriptrayoftheCS220PROcoffee
machineaccordingtoillustration.
Thepositionsofthedrillholesaremarkedattheundersideofthedriptrays.
CS220PROnewdriptrays
ThedriptraysoftheCS220PROcoffeemachinehavebeenmodifiedwithinsertsfor
lattemacchiatopreparation.
1. Drillahole(7mmdia)intheleftandrightdriptrayoftheCS220PROcoffee
machineaccordingtoillustration.
Thepositionsofthedrillholesaremarkedattheundersideofthedriptrays.
Riskofdamage!
Thedrillcanjam
andteartheplastic.
Pilotdrillholes.
Riskofdamage!
Thedrillcanjam
andteartheplastic.
Pilotdrillholes.
