O P E R A T I O N
6. Insertsixnewcapsuletubesintubeconnectors(7):
• Rotatetubeconnectordownfully.
• Insertcapsuletubewithopenendintubeconnector.
Donotforgettopulloffthealuminiumfoilfromthecapsuletubeatfirst.
Insertcapsuletubewitharotatingmovementuptothelimitstop.
7. Rotatetubeconnectorwithcapsuletubebackinverticalposition.
Thecoffecapsulesfallintothedispensermodulandtheassociatedoperating
buttonturnstowhite.
8. Closedoors(8)andlockkeyswitch(9).
Theautomaticcapsuledispenserisnowreadyforoperation.
Replacingemptycaspuletubes
Emptycapsuletubesareindicatedbyredlightedoperatingbuttons.
• Folddownemptycapsuletubeandpullitoutoftubeconnector(7).
• Insertnewcapsuletubeintubeconnectorandrotateitbacktoverticalposition.
Itisnotnecessarytowaitwithreplacementtillthedispensermodulisempty
andtheoperatingbuttonslightupred.Assoonasatubeconnectorcanbe
rotated,itscapsuletubecanbereplaced.
