| AlphaDisc CLD user guide V2.0
10
In order to connect the cables to the controller’s terminals, remove the top cover by loosening the four screws.
Remove the two screws that secure the electrical safety protection cover. This will allow access to connect the
external power supply.
NOTICE
the connection cables enter the controller case via silicon insulated holes. Once the silicon insulation is broken by
the cable it will no longer provide sufficient insulation without cable. Do not remove cables from entrance holes
without replacing them with the new ones!
NOTICE
every external device connected to the controller should be correctly set up in controller settings (see 5.3).
For example: number of filtration units must be specified correctly; type of analog device connected to the
controller must be specified in corresponding field.
