| AlphaDisc CLD user guide V2.0
11
3.4 ALPHADISC™ CLD DP SENSOR CONNECTIONS
The AlphaDisc™ CLD controller can work with an internal or external DP sensor, depending on configuration.
The controller’s default configuration is the internal DP sensor. Water pipes should be connected to the DP inlet and
outlet (See Figure 1: AlphaDisc™ CLD controller components).
Water connection Water connection
