| AlphaDisc CLD user guide V2.0
54
4.5 GETTING TO KNOW THE ALPHADISC™ BLE MOBILE APPLICATION
Take a few moments to familiarize yourself with the AlphaDisc™ BLE Mobile Application interface.
AlphaDisc™ BLE Mobile application consists of Sites List screen, containing the list of all paired controllers, Menu
screen, and Site tabs that are available for each active site. See details in the following tables.
4.5.1 Screens Details
4.5.1.1 Sites List Screen
ELEMENT DESCRIPTION
MENU BUTTON OPENS MENU SCREEN (SEE 4.5.1.2)
ADD NEW SITE BUTTON STARTS PAIRING PROCESS FOR NEW SITE.
LIST OF PAIRED SITES
LIST OF ALL PAIRED SITES. CLICKING ON ACTIVE SITE WILL OPEN SITE TABS (SEE 4.5.1.3).
EACH ELEMENT OF THE LIST CONTAINS FOLLOWING INFORMATION:
• SITE PICTURE
• SITE NAME
• BLUETOOTH® ICON – BLUE WHEN AVAILABLE AND GREY WHEN OUT OF RANGE
