| AlphaDisc CLD user guide V2.0
45
4.4 GETTING TO KNOW THE ALPHADISC™ CLD MOBILE APPLICATION
Take a few moments to familiarize yourself with the AlphaDisc™ CLD Mobile Application interface.
AlphaDisc™ CLD mobile application has eight main screens. Every application screen has a Header line containing the
Menu button and screen name. You can switch between the app screens using the Menu button. See details in the
following tables.
4.4.1 Header Line Details
4.4.2 Menu Details
ELEMENT DESCRIPTION
MENU BUTTON OPENS THE MENU TO SWITCH BETWEEN SCREENS.
SCREEN NAME THE NAME OF THE CURRENT SCREEN.
ELEMENT DESCRIPTION
UPPER RED AREA CONTAINS USER NAME AND ACCOUNT EMAIL.
MONITORING
SITES
OPENS SITES SCREEN. THE SITES SCREEN CONTAINS THE LIST OF ALL OWNED AND LINKED
SITES AS WELL AS SITES OVERVIEW AND SETTINGS, AND ADD SITE BUTTON. SEE 4.4.3.1.
MONITORING
SITES MAP
OPENS SITES MAP SCREEN. THE SITES MAP SCREEN CONTAINS THE MAP WHERE ALL
OWNED AND LINKED SITES ARE MARKED, AS WELL AS ADD SITE BUTTON. SEE 4.4.3.2.
MONITORING
ALERTS
OPENS ALERTS SCREEN. THE ALERTS SCREEN CONTAINS ACTIVE ALERTS FROM ALL
CONNECTED CONTROLLERS AND A LIST OF ALERT MESSAGES ACCORDING TO THEIR
OCCURRENCE TIME AND DATE. SEE 4.4.3.3.
SETTINGS
SITES MANAGER
OPENS SITES MANAGER SCREEN. THE SITES MANAGER SCREEN CONTAINS A LIST OF ALL
OWNED AND LINKED SITES, AS WELL AS ADD SITE BUTTON. SEE 4.4.3.4.
SETTINGS
LOCALIZATION SETTINGS
OPENS LOCALIZATION SETTINGS SCREEN THE LOCALIZATION SETTINGS SCREEN CONTAINS
LOCALIZATION PARAMETERS – LANGUAGE AND UNITS. SEE 4.4.3.5.
INFORMATION
SUPPORT
OPENS SUPPORT MESSAGE CENTER. SEE 4.4.3.6.
INFORMATION
USER MANUAL
OPENS USER MANUAL SCREEN, CONTAINING A LINK TO THE DIGITAL VERSION OF THE USER
MANUAL. SEE 4.4.3.7.
ACCOUNT
PROFILE
OPENS PROFILE SCREEN. THE PROFILE SCREEN CONTAINS ACCOUNT PARAMETERS. SEE
4.4.3.8.
ACCOUNT
SIGN OUT
CLICK IT TO SIGN OUT OF THE ACCOUNT.
