4.3.3.4 Alerts Page
The Alerts page contains active alerts from all connected controllers and a list of alert messages according to their
occurrence time and date.
The Alerts page contains the following elements:
ELEMENT DESCRIPTION
ACTIVE/HISTORY BUTTONS
CLICK ACTIVE TO SEE THE LIST OF ACTIVE ALERTS FOR THE SPECIFIC CONTROLLER.
CLICK HISTORY TO SEE THE LIST OF ALERT MESSAGES ACCORDING TO THEIR OCCURRENCE
TIME AND DATE.
TIME SPAN BUTTONS
AVAILABLE ONLY ON HISTORY TAB. CLICK DAY/WEEK/MONTH BUTTON TO SELECT DESIRED
LIST'S TIME SPAN. BY DEFAULT, LAST WEEK EVENTS ARE SHOWN.
DATES SELECTION
AVAILABLE ONLY ON HISTORY TAB. ENABLES SHOWING EVENTS BETWEEN TWO DATES.
SELECT THE DESIRED LIST'S TIME SPAN.
ALERTS LIST
DISPLAY THE ACTIVE ALERTS OR THE LIST OF ALERT MESSAGES ACCORDING TO THEIR
OCCURRENCE TIME AND DATE (ACTIVE/HISTORY TAB). SEE APPENDIX B. ALARMS AND
FAULTS LIST.
PAGE NAVIGATION USE ARROWS IN BOTTOM LEFT CORNER TO SWITCH BETWEEN PAGES.
LINES PER VIEW
USE DROP-DOWN LIST IN BOTTOM RIGHT CORNER TO CHOOSE HOW MANY LINES WILL BE
DISPLAYED ON ONE PAGE.
