ELEMENT DESCRIPTION
SOLENOID PULSE LENGTH
SET THE PULSE LENGTH FOR SOLENOID IN MS.
DEFAULT VALUE: 80 MS.
END OF CYCLE RELAY OUTPUT
SET THE RELAY OPERATION ON END OF CYCLE EVENT (OFF / ON).
DEFAULT VALUE: OFF.
SET THE RELAY OPERATION TIME.
DEFAULT VALUE: 10 SEC.
ALARM RELAY
SET THE RELAY OPERATION ON ALARM EVENT (OFF / ON).
DEFAULT VALUE: OFF.
WATER METER
WATER METER INPUTS ALLOW CONNECTING EXTERNAL WATER METERS TO ALPHADISC™
CLD, RECORDING THE VALUES, AND COMPARING WITH FILTER SYSTEM VALUES / EVENTS.
WATER METER INTERVAL (MIN) – SAMPLING INTERVAL FOR FLOW RECORD.
DEFAULT VALUE: 30 MIN.
WATER METER 1
WATER METER SETTING PROPERTIES:
WATER METER PULSE VOLUME (LITER).
DEFAULT VALUE: 100 LITERS.
WATER METER ROLE (MAIN LINE / FLUSH) – SET THE WATER METER AS IT IS ASSEMBLED ON
THE MAIN LINE OR ON THE FLUSH LINE.
UNIT (LITER / GALLON).
DEFAULT VALUE: LITER
WATER METER 2
ANALOG INPUT
ANALOG INPUT ALLOWS CONNECTING EXTERNAL ANALOG SENSOR TO ALPHADISC™ CLD,
RECORDING THE VALUES, AND COMPARING WITH YOUR FILTER SYSTEM VALUES / EVENTS
(AS PRESSURE, TEMPERATURE, CONDUCTIVITY, TURBIDITY, HUMIDITY).
SAMPLING INTERVAL FOR RECORD:
STABILIZATION TIME – THE TIME TO WAIT FROM SENSOR POWER UP UNTIL MEASUREMENT
START.
DEFAULT VALUE: 1 SEC.
ANALOG INPUT INTERVAL – SAMPLING INTERVAL FOR ANALOG INPUT VALUE RECORD.
DEFAULT VALUE: 1 HOUR.
ANALOG INPUT 1
ANALOG INPUT SETTING PROPERTIES:
INPUT TYPE (VOLT / MA) – SELECT THE INPUT TYPE.
DEFAULT VALUE: MA
LOWER VALUE (4 MA / 0 VOLT) – SET THE LOWER VALUE.
HIGHER VALUE (20 MA / 10 VOLT) – SET THE HIGHER VALUE.
SENSOR TYPE (PRESSURE, TEMPERATURE, CONDUCTIVITY, TURBIDITY, HUMIDITY).
UNITS (BAR/PSI, CELSIUS/FAHRENHEIT, S/M, NTU, %).
DEFAULT VALUE: BAR.
ANALOG INPUT 2
FREEZING PROTECTION
FREEZING PROTECTION – THIS FUNCTION IS TO PREVENT THE FILTER FROM FREEZING IN
LOW TEMPERATURE WHILE IT IS CONNECTED TO WATER SOURCE.
DEFAULT VALUE: ENABLE
LOW TEMPERATURE THRESHOLD – TEMPERATURE SETPOINT TO START FILTER FLUSHING.
DEFAULT VALUE: 4°C.
PROTECTING FLUSHING INTERVAL – FLUSHING INTERVAL WHILE FREEZING PROTECTION IS
ACTIVATED.
DEFAULT VALUE: 60 MIN.
LCD DISPLAY UNIT ALLOWS SWITCHING UNITS ON THE CONTROLLER SCREEN BETWEEN BAR AND PSI.
NOTICE
Make sure to press SAVE after changing any of the above settings.
