INSTALLATION
CHECKLIST
1. Assemble and install remote control valve and pressure regulator as indicated in
Netafim detail(s) .
2. Assemble and install supply header as indicated in Netafim detail(s)
. Tape or plug all open connections.
3. Assemble and install exhaust header as indicated in Netafim detail(s)
. Tape or plug all open connections.
4. Install Techline CV laterals beginning at the start connection(s) indicated in Netafim
detail(s) . Type and layout of laterals are to be
installed as specified, and/or as indicated in Netafim detail(s) .
Tape or plug all open ends.
5. If required, install an air/vacuum relief valve at the point(s) of highest elevation in the
zone as indicated in Netafim detail(s) .
6. Make all Techline CV to fitting connections while flushing the system. Make
connections as indicated in Netafim detail(s) .
7. While flushing, connect Techline CV laterals to the exhaust header as indicated in
Netafim detail(s) .
8. Install line flushing valve(s) as indicated in Netafim detail(s) .
9. Install other Netafim accessories as indicated in Netafim detail(s) .
10. Operate and inspect the system. Record system data for historical record. Use
Netafim System Inspection Checklist.
Project:
Date:
