Page #6 background image
N E T A F I M T E C H L I N E
®
C V D E S I G N G U I D E
5
N E T A F I M T E C H L I N E
®
C V D E S I G N G U I D E
BASIC
DESIGN
STEPS
Dripper Flow
Dripper Interval
Lateral (Row) Spacings
Burial Depth
Application Rate (in./hr.)
Time to Apply
1
/4"
of Water (in minutes)
Clay Soil
0.26 GPH
18"
18" - 22"
.19 - .15
79 - 100
Loam Soil
0.4 GPH
12"
18" - 22"
.43 - .35
35 - 43
Sandy Soil
0.6 GPH
12"
12" - 16"
.96 - .72
16 - 21
Clay Soil
0.26 GPH
18"
18" - 24"
.19 - .14
79 - 107
Sandy Soil
0.6 GPH
12"
16" - 20"
.72 - .58
21 - 26
Loam Soil
0.4 GPH
18"
18" - 24"
.29 - .21
52 - 71
SHRUB and GROUND COVERTURF
TECHLINE
®
CV
General Guidelines
Maximum s
p
acin
g
recommendations: Followin
g
these s
p
acin
g
g
uidelines
,
dri
pp
er flow selection can be increased if desired b
y
the desi
g
ner.
On-surface or bury evenly throughout the zone to a maximum of 6 inches
TABLE 1
WHEN SHOULD YOU USE TECHLINE CV?
Anytime you want to create an even wetted pattern of water throughout an area.
Since the object of sprinklers is also to create an even wetted pattern, you can use Techline CV
anytime you can use sprinklers.
CHOOSING THE PROPER TECHLINE CV:
From Table 1, answer two questions:
1. Are you irrigating a Shrub & Groundcover area or Turf?
2. Is the soil Clay, Loam or Sandy?
Follow the proper column listed under TURF or SHRUB & GROUNDCOVER to identify the proper
Techline CV. Example - If you choose Shrub & Groundcover, with loam soil, 0.4 GPH/18” Techline CV is
the proper choice. (Each dripper will deliver 0.4 GPH and the drippers, mounted inside the tubing, are
spaced 18” apart.)
What other information is in the General Guidelines Chart?
1. How far to spread out the laterals is listed on the “Lateral (Row) Spacings” line.
(For this example, rows should be evenly spaced anywhere from 18” - 24” apart.)
2. The corresponding application rates and time to apply are listed under the Lateral Spacings
line. (With rows of 0.4 GPH/18” Techline CV every 18” apart, the application rate is 0.29 inches
per hour and it will take 52 minutes to apply
1
/4” of water. If the rows are 24” apart, the application
rate is 0.21 inches per hour, and it will take 71 minutes to apply
1
/4” of water. For other row
spacings, see page 26.)
