DESIGN
CRITERIA
• Designing with Techline CV follows the same basic rules as designing with Techline, sprays and rotors.
• Point of connection, static and operating pressures, flow rates, and type of materials being irrigated are
the same.
• Designing similar areas into a zone and not mixing products with different application rates is just like
sprinkler design.
• The essential differences include knowing the type of soil you are working with, and the method of
layout you use in the design.
SITE SURVEY:
• Obtain or draw a scaled plan of the site to be irrigated. Identify all slopes on the plan.
• Identify the type of soil (sand, loam or clay).
• Determine types of materials to be irrigated, turf, groundcover, shrubs, plants, and trees.
POINT OF CONNECTION:
• Type of water, potable, well, pump, effluent, etc.
• Pressure & volume available - Static and operating tests.
Note: For Techline CV Technical Product Application & Specifications, see page 22.
