1 E2800 controller (storage controller)
2 E5700SG controller (compute controller)
3 Power-fan canisters
Model SG5760
This figure shows the front and back of the SG5760 model, a 4U enclosure that holds 60 drives in
5 drive drawers.
The SG5760 includes two controllers, two fan canisters, and two power canisters.
Hardware Installation and Maintenance Guide for SG5700 Appliances 5
StorageGRID appliance overview
