Statistics – WAN Service
The Statistics – WAN Service page shows detailed information about the number of bytes, packets, errors and dropped packets on
the WAN interface in both directions of communication.
INTERFACE
DESCRIPTION
Received/Transmitted
Bytes
Rx/Tx (receive/transmit) packets in bytes.
Packets
Rx/Tx (receive/transmit) packets.
Errors
Rx/Tx (receive/transmit) packets with errors.
Drops
Rx/Tx (receive/transmit) packets with drops.
Statistics – xTM
The Statistics – xTM page shows details related to the xTM (ATM/PTM) interface of the router.
INTERFACE
DESCRIPTION
Port Number
The port number used by the xTM interface.
In Octets
The number of data packets in octets received over the ATM interface.
Out Octets
The number of data packets in octets transmitted over the ATM interface.
In Packets
The number of data packets received over the ATM interface.
Out Packets
The number of data packets transmitted over the ATM interface.
In OAM Cells
Operation, Administration, and Maintenance (OAM) Cell is the ATM Forum specification for cells used to
monitor virtual circuits.
Out OAM Cells
Operation, Administration, and Maintenance (OAM) Cell is the ATM Forum specification for cells used to
monitor virtual circuits.
In ASM Cells
The number of Any Source Multicast (ASM) cells received over the interface.
Out ASM Cells
The number of Any Source Multicast (ASM) cells transmitted over the interface.
In Packets Errors
The number of packets with errors detected over the xTM interface.
In Cell Errors
The number of cells with errors detected over the xTM interface.
